Waste compactors for chain-lift trucks

...wherever large quantities of waste or recycling material arise

AVERMANN waste compactors are produced in a solid and robust steel construction. More than 40 years of experience in the field of compactor production as well as a sophisticated technology and high-grade processing, guarantee a longevity of the machine. Due to many possible variations AVERMANN waste compactors offer the best solution of any kind of application. The compactors are built in a conical way so that they can be discharged easily.

* Feed-opening cover: protects the feeding area i.e. from rain water or from filling by unauthorized people.

* Round-up sealing on the rear-door and additional 4-point locking for a watertight discharging door.

* Modem connection to send the filling degree and/or fault codes by SMS, language or e-mail to the waste disposal company.

Technical data

	MPC-2/4X	MPC-04	MPC-05	MPC-06	MPC-08	MPC-10	MPC-12
Machine length	2500 mm	3200 mm	3510 mm	4010 mm	4010 mm	4375 mm	4875 mm
Machine width	1340 mm	1760 mm	1945 mm	1945 mm	1945 mm	1990 mm	1990 mm
Machine height	1555 mm	1580 mm	1780 mm	1780 mm	2230 mm	2460 mm	2460 mm
Net capacity	2 m³	4 m³	5 m³	6 m³	8 m³	10 m³	12 m³
Dead weight	1245 kg	1640 kg	2280 kg	2390 kg	2560 kg	3000 kg	3200 kg
Feed-opening width	1080 mm	1610 mm	1610 mm	1610 mm	1610 mm	1570 mm	1570 mm
Feed-opening depth	500 mm	670 mm	670 mm	670 mm	670 mm	1000 mm	1000 mm
Feeding height	1100 mm	1180 mm	1180 mm	1180 mm	1180 mm	1380 mm	1380 mm
Motor power	2,2 kW	5,5 kW	5,5 kW	5,5 kW	5,5 kW	5,5 kW	5,5 kW
Oil quantity	15 l	30 l	30 l	30 l	30 l	60 l	60 l
Capacity/working cycle	0,25 m³	0,7 m³	0,7 m³	0,7 m³	0,7 m³	1,00 m³	1,00 m³
Time/working cycle (empty)	30 sec	16 sec	21 sec	21 sec	21 sec	21 sec	21 sec
Press force	110 kN	210 kN	210 kN	210 kN	210 kN	380 kN	380 kN
Electric supply	3 x 400 V/50 Hz
Fuse protection on site	25 A, slow
Externally mounted plug	CEE-5 x 32 A/6 h
Compacting ratio	1:5
Transport system	Chain-lift or Chain-lift by telescopic cylinders (MPC-12)
